Ai P12M 12L/min SST Peristaltic Pump ETL

A peristaltic pump, also commonly known as a roller pump, is a type of positive displacement pump used for pumping a variety of fluids. The fluid is contained within a flexible tube fitted inside a circular pump casing (though linear peristaltic pumps have been made). A rotor with a number of “rollers”, “shoes”, “wipers”, or “lobes” attached to the external circumference of the rotor compresses the flexible tube. As the rotor turns, the part of the tube under compression is pinched closed (or “occludes”) thus forcing the fluid to be pumped to move through the tube. Additionally, as the tube opens to its natural state after the passing of the cam (“restitution” or “resilience”) fluid flow is induced to the pump. This process is called peristalsis and is used in many biological systems such as the gastrointestinal tract. Typically, there will be two or more rollers, or wipers, occluding the tube, trapping between them a body of fluid. The body of fluid is then transported, at ambient pressure, toward the pump outlet. Peristaltic pumps may run continuously, or they may be indexed through partial revolutions to deliver smaller amounts of fluid.

Source: Wikipedia

Specifications

Model	P12M
Electrical requirements	110V-230V, with auto intelligent voltage recognition   50/60Hz, 1-Phase 500 watts
Power cord	110V US 3-prong (comes with purchase)  230V cord (available upon request)
Pumping rate	12L/min (3.2 gallon/min)
Max. rotation speed	600 rpm (at 0.1 rpm step)
Pump head	Y35
Max. tubing size	5/8″
Controller	Type: analog  Distribution: 0 to 9999 times  Distribution timer: 0.1 second to 9999 minutes  Distribution interval: 0.1 second to 9999 minutes
Fluid retainment	Pump roll back: 10 to 720 degrees (at 1 degree step)  Speed: 10 to 300 rpm
Working temperature	0 to 40°C, < 80% humidity
IP rating	IP31
Communication port	Included: Remote on/off switch  Optional: RS485, 0-5V, 0-10V, 4-20mA input.       PLC control of pump’s start, stop, speed and rotation directions.
Unit/shipping dimensions (WxDxH)	9 x 18 x 9″ / 15 x 24 x 17″
Unit/shipping weight	20 Lbs
Compliance	ETL tested to UL and CSA standards
Warranty	One year







Standard package

Part description	Quantity	Part image
Ai P12M peristaltic pump	1 set
Silicone tubing (9.6mm ID, 16.2mm OD)	6.5 ft
Hose barb adapter	2 pcs
Remote on/off switch – 75 inches	1 pc
110V US 3-prong power cord (230V cord upon request)	1 pc
User’s manual	1 pc
