Ai SolventVap Rotary Evaporator Vapor Duct with Sealing Gasket
$90.00 – $140.00
High quality glass vapor duct with sealing gasket for Ai SolventVap series rotary evaporators.
Ai 1st Gen small-neck 10L evaporation flask mouth dimensions : ID 3 inches, OD 3 3/4 inches
Glass material: high borosilicate glass 3.3
Dimensions:
SE.VD.SE05
OD (Center Tube) : 22mm
ID (Condenser Side): 15.6 mm
ID (Flask Side): 14.2 mm
L: 194 mm
SE.VD-SE13
OD (Condenser Side): 39.7 mm
OD (Flask Side): 28.7 mm
ID: 21.7 mm
L: 157 mm
SE.VD.SE26 (small neck)
OD (Condenser Side): 59.1 mm
OD (Flask Side): 49.6 mm
ID: 39.1 mm
L: 189 mm
SE.VD 10-50L
OD(Condenser Side): 70.1 mm
OD (Flask Side): 60.2 mm
ID: 49.4 mm
L: 188 mm
Tolerance: Tolerance: +/-1 mm
�
