** Some Pics & Specs for Reference Only – Call for Details **
Two Cascade CVO-5 vacuum ovens powered by a single Agilent IDP15 9 cfm Oil Free Scroll Pump set-up for high throughput with deep vacuum and large off-gas loads. The MAXTRAP50 is a -50°C cold trap that extends time between pump maintenance and traps contaminants. The system components are NRTL Certified and available in Stainless Steel.
CVO-5 Vacuum Oven Features
NRTL Certified by TUV
5 each adjustable shelves
Stable temperature control. Digital temperature readout with temp sensor INSIDE the oven
Bright LED lights in window for visibility of sensitive material
Touchscreen LED Control Panel with adjustable settings
Smooth, quarter-turn vacuum and vent valves
Energize vacuum pump from control panel
Rear KF-25 port allows for rapid MAXEVAP purging or running feedthroughs inside oven for monitoring
120V or 220V power options are available
Quality Tempered Rated Glass NGI-US to ANSI Z97.1.2007 156CFR/201 11 SGCC -2577 ½ UA
Adjustable leveling feet insure your unit sits solid and level in the workspace
Stainless Steel option available
Made in USA
Agilent IDP15 Oil-Free Scroll Pump Features
Quiet. Less noisy that diaphragm or oil-rotary vane pumps
Oil Free. No Inlet / Exhaust Filters Required
Hour Meter For Tracking Service Intervals
1 Year Warranty
NRTL Certified
Expert Rebuild/Maintenance Available from Cascade
Maintenance is the replacement of a single interior tip seal. Order our IDP15 Tip Seal Replacement Kitor ask us about our maintenance service.
Pull Deeper Vacuum / Better Vapor Tolerance With Gas Ballast Positions. The IDP15 has two gas ballast ports that assist the pump in handling condensable gases such as water vapor, or other gaseous products that become liquids or solvents when reaching atmospheric pressure.
MAXTRAP50 Cold Trap
Temperatures to -50°C
UL & CSA Certified
Eco Refrigerants
4 ft of 1″ Dia Vacuum Tubing with KF-25 Flanges on each end, KF-25 clamps, centering rings
Large KF-25 Inlet & Outlet
Stainless Steel COLDWELL Trap Insert
The CVO-5 vacuum oven offers incredible temperature stability for vacuum drying and purging of pharmaceuticals, botanicals, slurries, or any temperature sensitive material. This vacuum oven will liberate solvents, water or other unwanted compounds in a small batch, R&D, laboratory environments.
The system is mounted on industrial-grade, mobile racks for mobility and ease of cleaning the laboratory. Casters are lockable.
Vacuum oven and pump are connected via our MAXEVAP Connection Kit – giving water, solvents, surfactants, any outgassing material the largest exit path off the product and out of the oven. The MAXEVAP Connection Kit features a large 1″ diameter oven exit port, KF-25 lines and a KF-25 precision adjustable vacuum valve to reduce purge and dry times. Our KF-25 pump manifold allows both ovens to be sufficiently powered by a single vacuum pump.
The MAXTRAP105 provides a high thru-put cold trap.
Two each Cascade Sciences CVO-5 Vacuum Ovens
A total of 10 each removable, height adjustable aluminum shelves
To 105°F (40°C) 60 minutes
To 200°F (90°C) 126 minutes
To 300°F (150°C) 180 minutes (170 minutes for 220V version)
COOL DOWN TIME
From 105°F (40°C) 345 minutes
From 200°F (90°C) 285 minutes
To 300°F (150°C) 335 minutes (460 minutes for 220V version)
*Temperature performance specifications are preformed in empty ovens. Performance can vary in ovens containing product, ambient lab conditions.
VACUUM VALVE
¼ Turn Lever
VENT VALVE
¼ Turn Lever
INTERIOR LIGHTING
LED Strips (Rated to 150°C)
GLASS WINDOW
Tempered NGI-US to ANSI Z97.1.2007
VACUUM GAUGE
Digital, selectable to read in inches mercury (Hg) or torr, barr
CONTROLLER
Touch Screen
Accurate Within 1°F
Independent Overtemp Failsafe
Easy updates with USB port
PORTS (REAR)
Vacuum = 3/8th Barb
Vent = ¼” Barb
Auxiliary KF-25 Port for MAXEVAP Connection Kit
INERT GAS INTRODUCTION
Yes. Via ¼” Vent Barb
15 psi max inlet pressure
POWER
110V – 120V / 1ph / 14A 50/60Hz
Cord Included
NEMA 5-15 Power Outlet
1105 BTU/hr
Rating at max power
220V – 240V / 1ph / 7A 50/60Hz Available
Cord Included
NEMA 6-15R Power Outlet
1228 BTU/hr
Rating at max power
INCLUDED ACCESSORIES
5 Shelves
20 Clips
4 Leveling Feet
Power Cord
DOOR GASKET
18” x 18” Cured Silicone
Temp Silicone rated to 446°F(230°C)
SHIPPING DIMENSIONS
41”L x 41”W x 45”H
Class 85
Shipping Weight: 449 lbs / 204 Kg
CERTIFICATIONS
ISO 9001
NRTL TUV #U8 170464972 077
CAN/CSA-C22.2 No. 61010-1:2012
+ UPD No. 1:2015-07 + UPD No. 2:2016-04
CAN/CSA-C22.2 No. 61010-2-010:2015
UL 61010-1:2012/R:2016-04
UL 61010-2-010:2015
EN 61010-1:2010
EN 61010-2-010:2014
WARRANTY
1 Year (gaskets not included)
Agilent IDP15 Pump
220V-230V/1ph/3AMP
120V/1ph/5AMP
*m/sec AMP surge at start up
Noise level: 50dBA ±2dBA
Operating Temp: 5°C-40°C / 41°F-104°F
Oil-Free, Scroll
9 CFM
10 x 10-3 Torr
Intake Connection KF-25
L 19.08” x W 9.22” x H 14.3”
Weight; 75 lbs
MOBILE RACK
Overall Dimensions – see dimensional drawing
MAXTRAP50 Cold Trap
COLDWELL STAINLESS TRAP INSERT:
KF25 Inlet & Outlet
3 Quart Capacity (2839 mliters)
Viton Gasket
Neoprene Insulator Cap
LABCONCO -105°C MECHANICAL BASE:
115V / 1ph / 13 AMP (60Hz)
Cord Included
CFC / HCFC Free Refrigerants
DIMENSIONS:
inches 24.1 W x 23.9 D x 12.6 H
cm 34.3 x 59.7 x 30.5
*Requires 800ml (~ 3.5 cups) of transfer fluid
(ethanol, glycol, cryo-cool fluids)
CONNECTIONS:
1 each 4′ KF-25 flanged vacuum rated line
1 each KF-25 Centering Ring
1 each KF-25 Clamp
