Julabo CORIO CD-BC6 Heating Circulator
$3,490.00 – $4,290.00
Julabo CORIO CD-BC6 Heating Circulator
Call for lead time
The new generation of laboratory circulators for routine work and standard tasks
CORIO™ heating circulators feature professional technology for high standards. These units facilitate internal temperature control in the bath tank or control of externally connected applications.
Your advantages:
-
- Models for internal and external applications
-
- Bright, white, easy to read display
-
- Very quiet
-
- Easy pump change-over between internal and external circulation
-
- USB connection
-
- High-quality bath tanks made of stainless steel with bath lid and drain tap
-
- Integrated cooling coil for counter-cooling
Technical Data
| Order No. | 9012506 |
|---|---|
| Model series | CORIO |
| Category | Heating Circulators |
| Working temperature range (°C) | +20 … +150 |
| Temperature stability (°C) | ±0.03 |
| Setting / display resolution | 0.01 – 0.1 °C |
| Temperature Display | LED |
| Heating capacity (kW) | 1 |
| Pump capacity flow rate (l/min) | 15 |
| Pump capacity flow pressure (psi) | 5.08 |
| Bath opening/bath depth (W x L / D inch) | 5.1 x 5.9 / 7.8 |
| Pump connections | M16x1 |
| Barbed fittings diameter (inner dia. / mm) | 8 / 12 |
| Filling volume (litres) | 4.5 … 6 |
| Ambient temperature | 5…40 °C |
| Dimensions W x L x H (inch) | 9.5 x 17.4 x 18.5 |
| Weight (LBS) | 22.1 |
| Included with each unit | 2 each barbed fitting for tubing 8 and 12 mm inner dia.(pump connections M16x1 male) |
| Cooling Coil | integrated |
| Bath tank | Stainless steel |
| Bath cover | integrated |
-
100% Checked.
100% testing. 100% quality. Each CORIO undergoes thorough quality testing before leaving the factory.
-
ATC.
Absolute Temperature Calibration, 1-point calibration (CD).
-
Brilliant.
Bright display with strong illumination can be viewed easily from a long distance.
-
Connection. Easy.
Inclined pump connections (M16x1) facilitate the connection of applications. Each unit includes 2 barbed fittings of 8/12 mm diameter each.
-
Everything at the front.
All operating controls and safety functions are accessed easily and comfortably from the front.
-
Green technology.
Development consistently applied environmentally friendly materials and technologies.
-
Handle with ease.
Makes day-to-day work easy. Comfortably move your CORIO around by using the ergonomic handles (front and rear).
-
Internal. External.
The pump is controlled via a lever located directly below the display. Easily change between internal and external circulation.
-
JULABO. Quality.
Highest standards of quality for a long product life.
-
Locked in.
The lockable power plug guarantees a safe connection. More process safety.
-
Modern. Reliable.
Every JULABO Circulator is equipped with high-grade components like i.e. platinum sensors, proven motor technology, CAN-Bus communication and much more.
-
Quick start.
Individual JULABO consultation and comprehensive manuals at your disposal.
-
Safety.
CORIO CD complies with Class III (FL) according to DIN 12876-1 and switches off automatically in case of high temperature or low liquid level alarm.
-
Satisfied customers.
11 subsidiaries and more than 100 partners worldwide guarantee fast and qualified JULABO support.
-
Services 24/7.
Around the clock availability. You can find suitable accessories, data sheets, manuals, case studies, and more at www.julabo.com.
-
Solid.
Minimized energy loss through high-quality insulation.
-
Stable.
Rubber feet allow for a secured footing of your CORIO to prevent damage to your laboratory equipment.
-
Switch on. And off you go.
Intelligent operating concept. Ready for operation with just a few quick and easy steps.
-
Tidy.
The special drain tap for easy draining of bath fluids without tools.
-
Touching permitted.
Optimum safety. The ergonomic plastic handle protects your fingers from hot surfaces.
-
Unique.
Specially designed pyramids ensure that the condensed liquid drips directly back into the bath.
-
USB.
Remote control made easy. CORIO CD circulators feature a USB connection.
Technical changes without prior notification.
Images may deviate from the original.
For applications near or below ambient temperature: use a cooling coil or JULABO immersion cooler.
