Julabo CORIO CP-1000F
Call for lead time
Refrigerated Circulators from the CORIO CP range are suitable for applications with a temperature range up to +200°C. The enhanced pump performance ensures they are suitable for easy temperature control tasks in combination with external applications.
Included with each unit: 2 each barbed fitting for tubing 8 and 12 mm inner dia. (pump connections M16x1 male)
Key Benefits:
- Models for internal and external applications
- Bright, white, easy to read display
- Very quiet
- Easy pump change-over (internal and external circulation)
- External pump connections (M16x1)
- USB & RS232 connection
- Space-saving cooling coil design yields more usable space in the bath tank
- Bath lid and drain tap included
- Removable ventilation grid
- Refrigeration unit without side vents
- Class III (FL) according to DIN 12876-1
| Technical Data | |
|---|---|
| Order No. | 9013707 |
| Model series | CORIO |
| Category | Refrigerated – Heating Circulators |
| Working temperature range (°C) | -50 … +200 |
| Temperature control | PID |
| Temperature stability (°C) | ±0.03 |
| Setting / display resolution | 0.01 – 0.1 °C |
| Temperature Display | LED |
| Heating capacity (kW) | 1 |
| Cooling capacity (Medium Ethanol) | °C 20 10 0 -10 -20 -30 -40 kW 1 1 0.9 0. 73 0.5 0.3 0.13 |
| Pump capacity flow rate (l/min) | 8 … 27 |
| Pump capacity flow pressure (psi) | 1.5 … 10.2 |
| Bath opening / bath depth (W x L / D inch) | 7.1 x 5.1 / 5.9 |
| Pump connections | M16x1 |
| Barbed fittings diameter (inner dia. / mm) | 8 / 12 |
| Filling volume (liters) | 5 … 7.5 |
| Refrigerant stage 1 | R449a |
| Filling volume refrigerant stage 1 (g) | 175 |
| Ambient temperature | 5…40 °C |
| Dimensions W x L x H (inch) | 16.5 x 19.3 x 27.6 |
| Weight (LBS) | 113.5 |
| Included with each unit | 2 Schlaucholiven passend für Schlauch 8 und 12 mm l.W. (Pump enanschlüsse mit M16x1 Außengewinde) |
| Bath tank | Stainless steel |
| Bath cover | integrated |
| Cooling of compressor | Air |
Specification: Julabo CORIO CP-1000F
|
